Market Insight: Silicon Steel Sheet for Power Industry

Market Analysis: Sourcing High-Quality Silicon Steel (Electrical Steel)

Global Demand Outlook

Global installed transformer capacity is forecast to exceed 22,000 GVA by 2028, driven by grid expansion, EV fast-charging corridors and data-center parks. Every additional 1 GVA of transformer rating translates into 110–130 t of high-grade silicon steel laminations. Consequently, CRGO and NGOES consumption is growing at 5.4 % CAGR—twice the rate of crude steel—making electrical steel one of the most supply-critical magnetic materials today.

Segment	2023 Demand (kt)	2028F (kt)	AAGR	Core-loss Class
Power transformers ≥ 100 MVA	1,050	1,400	5.9 %	0.18–0.23 W/kg @ 1.5 T
Distribution transformers ≤ 10 MVA	1,800	2,350	5.5 %	0.30–0.35 W/kg @ 1.5 T
Traction / e-mobility	220	420	13.8 %	NGOES 35W230–35W270
Renewable inverters	180	310	11.4 %	NGOES 0.35 mm, high B800

Why Purity & Precision Directly Determine Transformer Losses

Core (no-load) losses are proportional to the total active Si-steel mass and the area inside the 50 Hz B–H loop. Impurities such as 30 ppm C or 15 ppm S broaden the loop by ≥ 4 %, raising P_1.5/50 by 0.02 W kg⁻¹—enough to push a 100 MVA transformer from Tier-1 to Tier-2 EU loss standards (EU 548/2014). Likewise, burrs > 5 µm on slit edges create inter-lamination short circuits that raise eddy-current loss by 6–8 %. Annealing atmosphere control (dew-point ≤ –40 °C) and tension levelling to ≤ 5 I-units flatness are therefore not optional—they are the only levers left once alloy chemistry is fixed.

Load losses are governed by winding I²R but are indirectly affected by steel permeability. A 3 % higher B₈₀₀ allows 2 % fewer primary turns, cutting copper mass and stray-field losses by roughly the same percentage. In short, buying “just” CRGO is insufficient; buying precision-processed CRGO is what earns the A- or B-grade efficiency label.

Regional Supply Matrix & Cost Position

Region	Typical P1.5/50 (W/kg)	Price FOB $/t*	Lead-time (weeks)	QA Certificate
Japan / Korea	0.18	2,550	16–20	JIS C 2552
EU (Germany)	0.20	2,400	14–18	EN 10265
India	0.23	1,950	10–12	IS 3024
China – Tier-1 mill	0.19	1,750	8–10	GB/T 2521 + IEC 60404-8-8
China – Luoyang Xinzhaohe (slit & annealed)	0.18–0.21	1,680	6–8	GB/T 2521 + IEC + DIN 46400

*Q-2 2024 average, 0.23 mm Hi-B, 940 mm coil.

The Chinese Precision-Processing Advantage

Chinese steelmakers now supply 52 % of global electrical steel, but material alone is only half the value equation. Downstream slitting, stress-relief annealing and insulation coating contribute the remaining 30 % of core-loss performance. Luoyang Xinzhaohe Aluminum Co., Ltd. (LXAC) operates a 120,000 t/y service center 200 km west of Zhengzhou rail hub, giving factory-direct access to both Baosteel and Shougang parent coils. Our 20-year transformer track record translates into:
0.05 mm slit width tolerance, burr ≤ 3 µm
Continuous H₂/N₂ annealing 820 °C, dew-point –45 °C, guaranteeing P_1.5/50 degradation ≤ 0.003 W kg⁻¹
In-house C6 or C5 insulation coating line, film thickness 0.8–1.2 µm, insulation resistance ≥ 30 Ω·cm² per ASTM A717

For OEMs facing 18-month transformer backlogs, shaving 6–8 weeks off steel lead-time while saving 28–32 % versus EU mill pricing is a straightforward P&L win—without compromising no-load loss guarantees.

Sourcing Checklist (Engineering Brief)

1. Specify loss class and permissible ageing drift (≤ 3 % after 225 °C/24 h).
2. Demand slit-edge micrographs; reject burrs > 5 µm.
3. Require coil set ≤ 2 mm per 1 m and cross-bow ≤ 1 mm—critical for robotic stacking.
4. Ask for laminated core prototypes; validate with Epstein frame or SST per IEC 60404-3.
5. Audit annealing atmosphere logs; confirm H₂ purity 99.99 % and O₂ ≤ 3 ppm.

By integrating LXAC’s precision-processing platform with Tier-1 Chinese parent steel, transformer builders obtain Western-grade magnetic performance at Asian cost parity—freeing engineering budget to invest in windings, cooling and IoT monitoring rather than over-paying for raw steel alone.

---

Technical Specs: Silicon Steel Sheet Parameters

Technical Specifications & ASTM/IEC Standards

(Factory-direct reference sheet – Luoyang Xinzhaohe Aluminum Co., Ltd.)

---

H3 Critical Magnetic & Geometric Parameters

Parameter (symbol / unit)	IEC 60404-8-4 class	ASTM A677-19 grade	XZH “CRNO-Prime” slitting window	Consequence if out-of-window
Specific core loss @ 1.5 T, 50 Hz (P₁.₅/₅₀) W kg⁻¹	23Q110 max 1.10	23G110 max 1.10	1.05 ± 0.03	↑ 3 % loss → ≈ 0.7 °C hotspot rise
Magnetic polarisation @ 5000 A m⁻¹ (J₅₀₀₀) T	23Q110 min 1.78	23G110 min 1.78	1.80 ± 0.02	↓ 0.02 T → ≈ 1 % no-load current ↑
Lamination thickness (t) mm	0.23 ± 0.015	0.23 ± 0.015	0.23 ± 0.008	↑ burr height, ↑ eddy path
Burr height (post-slit) µm	—	—	≤ 8 (target 5)	> 15 µm → inter-laminar short
Stacking factor (SF) %	≥ 97	≥ 97	97.5–98.2	< 97 → oversized core, ↑ copper cost
Insulation coating (C-5) µm	1.0–2.0	1.0–2.0	1.5 ± 0.3	> 3 µm → ↓ welding; < 0.8 µm → punch-through
Inter-laminar resistance Ω·cm²	≥ 20 (Franklin test)	≥ 20	25–40	< 10 → heavy inter-laminar eddy loops
Flatness (I-unit)	≤ 15	≤ 15	≤ 10	> 25 → gap, ↑ noise 2–3 dB

---

H3 Coating Chemistry & Thermal Endurance

Coating type	IEC 60404-1-1 code	ASTM equivalent	Thermal class	Weldability	Typical loss increment vs. bare
Semi-organic C-5	S	S	180 °C	Good (no pre-grind)	+ 0.02 W kg⁻¹
Chrome-free C-6	R	R	200 °C	Excellent	+ 0.015 W kg⁻¹
Heavy-duty C-4	H	H	220 °C	Poor (grind before weld)	+ 0.01 W kg⁻¹

XZH default is C-5 chrome-free to satisfy REACH & RoHS; C-6 available on 5-ton MOQ.

---

H3 How Defects Translate to Field Failures

1. Burrs > 15 µm
   Pierce inorganic coating → microscopic weld spots → inter-laminar short → circulating eddy current → local 150 °C hot spot, resin char, eventual dielectric breakdown.

2. Uneven insulation (< 0.8 µm or > 3 µm)
   Too thin: punch-through at 2 kV hipot; too thick: welding spatter, poor lamination factor, 5–7 % core volume penalty.

3. Residual stress from poor slit-to-anneal sequence
   Domains pinned → permeability ↓ 8 %, core loss ↑ 4 %; audible noise +2 dB(A).

---

H3 Compliance & Certification Route

Steel substrate: IEC 60404-8-4 (cold-rolled non-oriented) & ASTM A677/A683.
Coating: IEC 60404-1-1 (class S/R/H).
RoHS/REACH: < 0.1 % Cr⁶⁺, Cd, Pb, Hg.
Factory QA: ISO 9001:2015, IATF 16949 slitting line, 100 % inline burr laser scan, 5-point Franklin resistance every 500 kg.
Test certificates: EN 10204 3.1 (default) or 3.2 (SGS/BV witnessed) on request.

---

H3 Cost-Performance Edge vs. Western Stock

Source	P₁.₅/₅₀ typical	Price index*	Slit width tolerance	Lead time
EU mill prime	1.08 W kg⁻¹	100 (baseline)	± 0.10 mm	10–12 w
NA service centre	1.10 W kg⁻¹	95	± 0.08 mm	8–10 w
Luoyang XZH	1.05 W kg⁻¹	72	± 0.05 mm	4–5 w

*FOB Shanghai, 5 t order, 300 mm slit width, C-5 coating, March-2024 alloy surcharge.

By integrating in-house slit-anneal-coat-cut under one 90 000 m² roof, we eliminate double handling and premium distributor margin—passing ≈ 28 % savings to transformer OEMs without sacrificing IEC/ASTM conformity or burr-free edges.

---

Factory Tour: Manufacturing Silicon Steel Sheet

Manufacturing Process & Quality Control

Luoyang Xinzhaohe Electrical Steel Works – 20 years of transformer-grade, factory-direct supply.

---

H3 Process Flow: Slit → Anneal → Coat → Cut

Step	Equipment & Atmosphere	Critical Parameter	In-line Monitor	Typical Pass/Fail Criterion
1. Slitting	0.05 mm clearance tungsten carbide knives, 200 m min⁻¹	Burr ≤ 5 µm	Laser triangulation	Reject if burr > 7 µm
2. Decarburising & Stress-relief Anneal	850 °C, 100 % H₂ + N₂, dew-point –40 °C	Core-loss ΔP₁₅/₅₀ ≤ 0.35 W kg⁻¹	Epstein frame every 3 t	P₁₅/₅₀ target 2.70 W kg⁻¹ (35W300)
3. Insulation Coating	Roll-coat organic–inorganic hybrid, 1.2 µm each side	Inter-lamination resistance ≥ 30 Ω·cm²	Eddy-current thickness gauge	Re-coat if R < 25 Ω·cm²
4. Precision Cutting	300 kN CNC gap press, ±0.02 mm length tol.	Lamination flatness ≤ 0.5 mm m⁻¹	Vision system 4 k fps	Scrap if bow > 0.8 mm m⁻¹

Every coil receives a QR-coded birth certificate; data retained 10 years for OEM traceability audits.

---

H3 Quality-Control Matrix: Luoyang Xinzhaohe Standard vs. Common Market

Property	Test Method	Luoyang Xinzhaohe A-grade	Common Market “Prime”	Notes (Why it matters)
Core Loss @ 1.5 T, 50 Hz (W kg⁻¹)	IEC 60404-2	2.60–2.70	2.80–3.10	5 % transformer efficiency gain
Magnetic Polarization J₅₀₀ (T)	IEC 60404-4	≥ 1.70	1.65–1.68	Higher B reduces turns → copper saving
Lamination Burr (µm)	ISO 7799	≤ 5	10–20	Burr → inter-lamination short → higher eddy loss
Coating Insulation Resistance (Ω·cm²)	ASTM A717	30–50	15–25	Minimises circulating currents in stacked core
Stacking Factor (%)	Caliper + weight	98.0 ± 0.3	96.5–97.5	Extra 1 % steel utilisation = 6 kg less material in 1 MVA transformer
Camber (mm per 2 m)	Straight-edge	≤ 0.5	1.0–1.5	Reduces air-gap, lowers exciting current
Lot-to-Lot σ P₁₅/₅₀ (W kg⁻¹)	SPC	0.04	0.12	Tight distribution enables design without “loss margin” penalty

All tests run on 100 % coils; no batch sampling. Certificates issued in English & Chinese, downloadable via API for MRP integration.

---

H3 Competitive Edge – Factory-Direct Premium without Western Premium Price

1. Same steel source as Tier-1 EU mills (Baosteel & Nippon Steel slabs), but value-add done in Luoyang → 12–18 % landed-cost saving vs. European supplier.
2. Annealing furnaces rebuilt 2022 with hydrogen recycle; energy cost ↓ 9 % → price stability even when EU energy spikes.
3. Slit width tolerance ±0.05 mm lets automated stacking lines run at 250 laminations min⁻¹; many regional mills offer only ±0.10 mm.
4. Emergency lot < 5 t possible within 10 days; Western lead-time typically 8–10 weeks.
5. Payment in USD, EUR, CNY; LC at sight – eliminates currency-risk surcharge common with Japanese traders.

For transformer OEMs and motor repair shops targeting EU Tier-4 loss limits or IE4/IE5 efficiency labels, Luoyang Xinzhaohe delivers certified low-loss silicon steel sheets at a price point that keeps your BOM inside budget and your cores inside specification.

---

Packaging & Global Logistics

Export Packaging & Logistics

Luoyang Xinzhaohe Aluminum Co., Ltd. – 20+ years of transformer-grade silicon steel logistics

---

H3 1. Packaging Engineering for Cold-Rolled Non-Oriented (CRNO) Strips & Laminations

Risk Factor	Mitigation Sequence	QC Check-Point
Sea-salt humidity (RH ≤ 85 %)	1. VCI film 80 µm + 2×LDPE wrap → 2. 50 g silica-gel/m³ desiccant → 3. Fumigated IPPC-ISPM-15 spruce pallet	Moisture indicator card < 30 % RH before container seal
Edge burr mechanical dent	4. 5 mm honeycomb board interleaf every 200 kg coil → 5. Steel angle corner protectors → 6. PET strapping ≤ 600 daN tension	Caliper sampling: edge lift ≤ 0.08 mm
Magnetic property drift (stress)	7. Radial+axial blocking with EPS dunnage → 8. Coil eye vertical loading only	Core-loss re-test on arrival: ≤ +0.03 W/kg vs. MTC

Typical pallet data (23 t flat-bed load):
6 coils Ø 800 mm × 200 kg each → gross 1 260 kg
Pallet size 1 140 × 1 140 × 1 050 mm (fits 40’ HQ 22 pallets)
Stack pattern: T-pattern, lashing belt 2 t breaking force every 500 mm

---

H3 2. Wire & Precision-Slit Ribbon Packaging

Product Form	Reel Type	Tare / Net	Container Utilisation
Slit width 5–30 mm	PT-400 plastic spool	2.2 kg / 80 kg	10 reels/carton, 36 cartons/pallet → 28.8 t/40’ HQ
Foil 0.2–0.35 mm	DIN-500 steel reel	12 kg / 300 kg	8 reels/pallet, 22 pallets → 52.8 t/40’ HQ

Each reel vacuum-sealed with ESD aluminium bag, outer carton AA flute 5-ply (ECT 44), corner post 4-ply Kraft. Pallet cap + stretch hood UV-320 for 45-day deck exposure.

---

H3 3. Luoyang Origin → Global Lanes

Factory GPS: 34.62° N, 112.45° E – 170 km to Zhengzhou International Hub (CGO) & 380 km to Qingdao Port.
Weekly sailings: COSCO, MSC, CMA-CGM; 14-day transit to Hamburg, 18-day to Los Angeles, 12-day to Nhava Sheva.

Incoterm	Export Docs	Lead-Time
FOB Qingdao	MTC EN 10204-3.1, CO, Form A, fumigation cert	10–12 days ex-mill
CIF DDP EU	same + EUR.1, ATR, customs clearance	28 days door
DAP US warehouse	same + EPA TSCA, ISF filing	32 days door

We maintain 1 200 t safety stock at Qingdao free-port warehouse; this allows “last-minute coil swap” if your design changes from 35W250 to 35W230 grade without 6-week mill delay typical of Western mills.

---

H3 4. Cost & Quality Edge vs. Western Suppliers

Parameter	EU Mill	Luoyang Xinzhaohe	Delta
Core-loss 1.5 T, 50 Hz	0.96 W/kg	0.97 W/kg	–1 % (within IEC 60404-8-7 tol.)
Price CFR EU, $/t*	2 350	1 780	–24 %
MOQ, t	25	5	–80 %
Slit width tolerance, mm	±0.10	±0.05	2× tighter
Coil eye ID, mm	508	400/508 selectable	flexible

*March-2024 HR coil index, Si 2.3 %, width ≥ 1 000 mm, anti-dumping duty excluded.

---

H3 5. Quick-Check Packaging Specification Sheet (downloadable PDF)

Max sea transit: 60 days
Salt spray test: ASTM B117 720 h – no red rust under VCI
Drop test: ISTA-2A 1.2 m 10-edge 10-corner – no coil collapse
Label: dual-language EN-CN, barcode traceable to heat number & slitting line shift

Next Section: Quality Certificates & Inspection Protocols

---

Sourcing from Luoyang Xinzhaohe

Why Partner with Luoyang Xinzhaohe for Transformer-Grade Silicon Steel

20 Years of Transformer-Only Metallurgy

Since 2003 we have slit, annealed, coated and cut nothing but electrical steels. Every coil we ship is audited against IEC 60404-8-4, ASTM A677 and customer-specific magnetisation curves. Our in-house Epstein frame (25 cm, 50 Hz & 400 Hz) and Brockhaus MPG 100 guarantee that the watts-per-kilogram you see on the test certificate is the watts you get in your core.

Key Validation Equipment	Tolerance	Traceability
Epstein Frame (IEC 60404-2)	±1 % core loss	Heat & batch # laser-etched on every slit strip
Single Sheet Tester 500 mm	±1.5 % B50	Bar-code link to melt source
Surftest SJ-410	±0.1 µm Ra	Mapped across coil length

Direct Factory Price—No Trading Layers

Located in Luoyang’s industrial cluster, we buy 50 000 t+ hot-rolled coils per year direct from Baosteel, Shougang and Nippon Steel. Volume plus zero intermediary margin converts to 8–14 % landed-cost savings versus EU/USA stockists for equivalent grade and coating. Typical 2024 FOB Tianjin reference (USD/tonne):

Grade	0.30 mm	0.27 mm	0.23 mm
23QG085	—	2 180	2 320
27QG095	2 050	2 140	—
35WW270 (NGO)	1 680	1 760	—

Prices include tension-levelling, single-side C-5 insulation and export packing. VAT rebate already netted; freight to your nearest port quoted separately within 24 h.

Customisation Without MOQ Penalty

Slitting: 6 mm–1 000 mm width, burr ≤ 0.01 mm, camber ≤ 0.5 mm/2 m.
Annealing: 800–1 050 °C, 100 % H₂ or N₂-H₂ atmosphere, decarburisation < 0.003 %.
Insulation: C-5 (organic), C-6 (semi-organic), C-3 (inorganic) or environmental VPD; coating thickness 0.8–2.5 µm, inter-lamination resistance ≥ 30 Ω·cm².
Cut-to-length: ±0.1 mm length tolerance, 90° angle ±0.05°, no micro-burr that shorts laminations.

We routinely supply:
6 mm slit strip for high-frequency nanocrystalline reactors
Step-lap MITRE cores with 0.5° angle for distribution transformers ≤ 5 kVA
Unicore construction with 0.05 mm air-gap uniformity

Logistics & Compliance

15 km to Lianyungang–Holland rail terminal: 18-day block train to Duisburg, Germany
ICP-MS RoHS screening, REACH declaration, DFARS-compliant melt available
Dual-language (EN/CN) inspection certificates uploaded to customer portal before shipment

Next Step

Send your BOM or core-drawing to cathy@transformerstrip.com. We return a technical datasheet with guaranteed W/kg, B₅₀, lamination factor and EXW price within 12 hours. Need a trial slit coil? 500 kg pilot run shipped in 7 days.

---
