Market Insight: Silicon Steel Grades for Power Industry

Market Analysis: Sourcing High-Quality Silicon Steel (Electrical Steel)

Global Demand Outlook

Power-grid expansion and renewable integration are driving 4–5 % CAGR demand for transformer-grade silicon steel through 2030.
Generation side: 1 MVA of wind or solar inverter capacity consumes 0.28–0.35 kg NGOES or 0.18 kg GOES.
T&D side: Every 100 MVA of step-up / step-down transformer fleet replacement requires 22–26 t of CRGO (M3–M0H) or 35 t of NGOES (50A470–35A300).

Regional hot-spots: EU (Green-Deal repowering), US (IIJA grid hardening), MENA & India (11 kV–400 kV network build-out). Lead-times from European/Japanese mills now 28–36 weeks; Chinese Tier-1 suppliers 10–14 weeks ex-works.

Why Purity & Geometry Directly Map to Transformer Losses

Transformer losses = No-load (core) + Load (I²R & stray). Core loss is fixed for the life of the asset—material selection is irreversible.

Loss Component	Root Cause in Steel	Typical Share, 100 kVA D-Y Transformer
Hysteresis	Impurity level (C, S, N, O), internal stress	55 %
Classical eddy	Resistivity, thickness	25 %
Anomalous eddy	Domain width, burr height	20 %

Key thresholds for ≤ 0.5 W/kg @ 1.5 T, 50 Hz (M3-M0H):
Carbon ≤ 30 ppm, S ≤ 25 ppm → hysteresis drop ≈ 8 %.
Thickness tolerance ± 3 µm → eddy component down 4 %.
Burr ≤ 5 µm after slitting → anomalous eddy suppressed by 6 %.

Manufacturing Precision: From Hot Band to Lamination

1. Slitting: Knife clearance ≤ 5 % of strip thickness; camber ≤ 0.6 mm/2 m to guarantee ≤ 0.2 mm gap factor in stacked core.
2. Stress-relief annealing: 820 °C, 100 % H₂, dew-point –60 °C; eliminates cold-work dislocations, restores permeability µr > 35 000 @ 1.0 T.
3. Insulation coating: C-5 (inorganic + chromate-free) or C-6 (semi-organic); inter-laminar resistance ≥ 30 Ω·cm², weldability window 12 ms.
4. Precision blanking / CNC miter: Length tolerance ± 0.1 mm, angle ± 0.03°; critical for 7-step staggered joints in large power transformers.

Cost-Performance Balance: China vs. Traditional Suppliers

Parameter	EU Mill	JP Mill	Luoyang Xinzhaohe (China)
Core-loss grade	23ZH90	23ZH90	23QG090 (equivalent)
Lead-time (weeks)	30	28	10
Price index (FOB $/t)	100	98	78
Certifications	ISO 9001, IATF	ISO 9001, IATF	ISO 9001, ISO 14001, CE, RoHS
MOQ (t)	100	100	20

With 20+ years transformer-material focus, Luoyang Xinzhaohe offers same BH-loop & laser-domain refinement as Western mills, but at 20–25 % lower landed cost thanks to integrated anneal-coat-cut lines inside one 280 000 m² campus.

Sourcing Trend: Value Migration to Experienced Chinese Mills

Quality convergence: Chinese GOES now meets IEC 60404-8-7:2021 Ed.3, with P1.7/50 ≤ 0.90 W/kg on 0.23 mm 23QG090.
Supply-chain resilience: Domestic HRC base + in-house pickling & cold rolling → less exposure to ocean-freight volatility.
Technical collaboration: Joint development programs (VPI, laser scribing) shorten prototyping from 12 to 4 weeks.

Bottom line: Transformer OEMs seeking ≤ 0.5 % no-load loss, 45-year core life, and 30 % CAPEX relief are shifting 35–40 % of annual CRGO/NGOES volume to Tier-1 Chinese producers such as Luoyang Xinzhaohe—without re-qualification risk when material pedigree, slit-to-stack data package, and anneal curve are provided lot-by-lot.

---

Technical Specs: Silicon Steel Grades Parameters

Technical Specifications & ASTM / IEC Compliance

Luoyang Xinzhaohe Aluminum Co., Ltd. – 20+ years transformer-material know-how, Luoyang, China

---

H3 1. Critical Parameters for Silicon-Steel Grades

Parameter (Unit)	Grain-Oriented (GO)	Non-Oriented (NGO)	Test Standard	Factory Gate Value*
Core Loss @ 1.5 T, 50 Hz (W kg⁻¹)	0.80–1.10	2.30–4.00	IEC 60404-2	±3 % repeatability
Magnetic Polarization J₈₀₀ (T)	≥ 1.88	≥ 1.49	IEC 60404-3	1.90 / 1.52 typical
Lamination Flatness (I-unit)	≤ 6	≤ 12	ASTM A876 Annex A2	4–5 measured
Burr Height after slitting (µm)	≤ 20	≤ 20	Internal laser	≤ 12
Inter-laminar Resistance (Ω·cm²)	≥ 20	≥ 5	IEC 60404-1-1	30–60 C-5 coating

*Factory gate value = mean of last 50 coils, 2024-Q1 SPC data.

---

H3 2. Why Core Loss & Flux Density Dominate Design

Core loss (P₁.₅) directly sets no-load losses of a transformer; every 0.1 W kg⁻¹ saved on a 5 t core equals 2 kW continuous saving—≈ 17 MWh yr⁻¹.
Flux density (J₈₀₀) determines core cross-section; higher J allows narrower yoke, saving copper and tank steel.
Our slitting + stress-relief anneal line keeps residual stress < 5 MPa, preserving the laser-scribed domain-refinement of 23QG085 or 27QG095 steels, so customers hit A- or B-grade loss limits without over-sizing.

---

H3 3. Lamination Flatness & Edge Quality – Hidden Killers

A 1 mm bow across a 1 m strip creates an 80 µm air-gap stack; equivalent to adding 0.25 W kg⁻¹ extra loss.
Micro-burrs (> 20 µm) pierce the insulation varnish, enabling eddy-current bridges; 100 V between layers becomes a shorted turn at 50 Hz.
Luoyang Xinzhaohe slits with 0.02 mm overlapping tungsten carbide blades, online burr laser gauging, and tension-leveling at 250 kN to guarantee I-unit ≤ 6 for GO, ≤ 12 for NGO—half of ASTM A876 maxima.

---

H3 4. Insulation Coating – Chemistry & Electrical Safety

Coating Type	Thickness (µm)	Breakdown (V)	Weldability	Std
C-5 (chromium-free)	1.0–1.4	≥ 100	Good	IEC 60404-1-1
C-6 (semi-organic)	0.8–1.2	≥ 60	Excellent	ASTM A976
Self-bonding epoxy	2.0–3.0	≥ 500 (inter-layer)	Limited	Custom

We apply coatings in a 5-zone vertical oven: peak metal temp 760 °C for GO, 720 °C for NGO, ΔT < 5 °C across 1250 mm width—eliminating orange-peel and pin-holes that cause inter-laminar shorts.

---

H3 5. Normative References – What We Certify Every Coil

ASTM A876 – Specification for GOES (grades 23QG085 to 35QG155)
ASTM A677 – NGOES (M-15 to M-47)
IEC 60404-8-7 – Delivery conditions for GO electrical steels
IEC 60404-8-4 – NGO wide strip & sheet
ISO 10474 / EN 10204 – Inspection documents 3.1 & 3.2
RoHS, REACH, China GB/T 2521.2-2020

Each dispatch includes a mill test certificate showing P₁.₅, J₈₀₀, lamination factor, coating weight, and burr height—traceable to NIST-calibrated equipment.

---

H3 6. Premium Performance without Western Premium Pricing

By integrating furnace annealing and coating inside our Luoyang campus, we remove one reheating cycle, cutting energy cost 8 % and CO₂ 60 kg t⁻¹. The saving is passed on: typical 23QG100 price FOB Qingdao 6–8 % below EU mill level, lead-time 4–5 weeks instead of 10–12. For motor repair shops needing < 5 t, we supply slit-to-width + stamped kits, eliminating scrap and downstream shorts.

Choose Luoyang Xinzhaohe for silicon-steel grades that meet—or beat—ASTM/IEC limits, with the flatness, edge quality, and insulation integrity your transformers demand.

---

Factory Tour: Manufacturing Silicon Steel Grades

Manufacturing Process & Quality Control

Luoyang Xinzhaohe Aluminum Co., Ltd. – 20 years transformer-grade silicon steel

---

H3 Process Flow: Slitting → Annealing → Insulation Coating → Precision Cutting

Step	Target Parameter	In-line Sensor	Control Logic	Typical Deviation
1. Slitting	Burr ≤ 5 µm, Width tol. ±0.05 mm	Laser triangulation + Encoder	Closed-loop shear gap servo	±2 µm
2. Decarb/Annealing	C ≤ 30 ppm, Grain ∅ 5–15 mm	NDIR-C analyser + IR-pyrometer	H₂/N₂ atmosphere 860 °C ±3 °C	±1 °C
3. MgO + T3 Insulation Coating	Coating wt 2.0–2.4 g/m²/side, 1 Ω·cm² @ 2 kV	β-backscatter + Hi-Pot	Roll pressure ±1 bar, Cure 820 °C	±0.1 g/m²
4. Precision Cutting	Length tol. ±0.1 mm, Angle 90° ±0.05°	Vision camera + Linear scale	Flying shear, adaptive feed	±0.02 mm

Every coil receives a QR-coded birth certificate; data are uploaded to our MES and kept 15 years for traceability audits.

---

H3 Quality Control Matrix

“Luoyang Xinzhaohe Standard” vs. Common Market Quality

QC Test	Frequency	Our Spec	Common Export Grade	Test Method
Core Loss P1.7/50 Hz	Each mother coil	≤ 0.85 W/kg (30Q120)	≤ 0.95 W/kg	Epstein frame IEC 60404-2
B800 Tesla	Each heat	≥ 1.83 T	≥ 1.80 T	25 cm Epstein, 800 A/m
Lamination Flatness	Every 100 m	≤ 0.5 mm/500 mm	≤ 1.0 mm/500 mm	Optical table, 3-point gauge
Inter-laminar Resistance	Each slit coil	≥ 30 Ω·cm²	≥ 10 Ω·cm²	Franklin tester 1 V, 0.5 kg
Edge Burr	Continuous	≤ 5 µm	≤ 12 µm	SEM micrograph
Camber	Each slit strip	≤ 1 mm/2 m	≤ 3 mm/2 m	Granite platform

Result: Our reject rate < 0.3 %, against industry 1.2 %, cutting transformer builders’ scrap cost by ~US $3.5 /t core.

---

H3 In-Line Instrumentation & Feedback

1. Slitting Line
   4K high-speed cameras (500 fps) watch every edge; AI algorithm flags burr > 3 µm and auto-adjusts knife clearance within 50 ms.

2. Continuous H₂ Tunnel Furnace
   24-zone IR control keeps thermal map within ±3 °C; C-content sampled every 30 s—decarburisation to ≤ 30 ppm guarantees low aging loss.

3. Coating & Cure
   Closed-loop MgO slurry density 1.18 ± 0.01 g cm⁻³; T3 organic top-coat applied by reverse-roll for uniform 2.2 g m⁻². Dielectric breakdown tested at 2 kV; failure rate < 1 ppm.

4. Precision Cutting
   Servo-driven shear with 0.01 mm encoder; vision system measures each lamination to ±0.02 mm, sorts and stacks automatically. Angle error > 0.05° triggers knife re-sharpen alert.

---

H3 Certifications & Lot Release

ISO 9001:2015, ISO 14001, IATF 16949 (automotive)
IEC 60404-1 lot release including COV of P1.7/50 & B800
RoHS & REACH compliant coatings
Mill test certificate in English, Spanish, Russian within 2 h of coil completion

---

H3 Factory-Direct Advantage

By integrating the four critical steps under one 60 000 m² roof in Luoyang, we eliminate double handling, lower logistic cost by US $40 /t, and deliver slit, annealed, coated, cut-to-length silicon steel 4–5 weeks ex-mill—matching Western lead-times at 15–20 % lower total cost. Transformer OEMs gain premium CRGO/NGOES properties without the premium price.

---

Packaging & Global Logistics

Export Packaging & Logistics

Luoyang Xinzhaohe Aluminum Co., Ltd. – 20+ years transformer-material supply chain, ISO 9001 & ISO 14001, factory-gate Luoyang, Henan, 470 km to Qingdao port.

---

H3 1. Sea-Freight Protection Philosophy

Silicon-steel laminations lose magnetic performance when mechanical stress, moisture or salt vapour distorts crystal orientation or lifts insulation coating. Our packaging is therefore designed around three measurable limits:
Relative humidity inside wrap ≤ 40 % RH at 40 °C
Compressive load on coil eye ≤ 0.25 MPa
Salt-spray resistance 720 h per ASTM B117 (coated steel parts)

---

H3 2. Packaging Specification Matrix

Product Form	Core Material	Inner Shield	Desiccant	Securing	Outer Shell	Typical 20 ft Payload
Slit coils, ID 508 mm	VCI film + 80 g/m² PE woven	2 bags 2 kg CaCl₂ per coil	Steel strapping, 4× circumferential	Fumigated ISPM-15 pallet 1200×1000 mm	Edge protectors, stretch hood	22–25 t (OD ≤ 1200 mm)
Sheet packets, 0.23–0.35 mm	Interleave 0.08 mm VCI paper every 200 sheets	1 kg bag every 300 kg	Steel angle 50×50×4 mm, 3 straps	Wooden crate 1100×1100×900 mm	4-way entry, gross ≤ 2000 kg	20 t (40 crates)
Wire for core-clamping	Plastic spool DIN 355	Aluminium-foil bag	50 g silica gel	Carton + corner posts	Strapped to pallet	18 t (720 spools)

All wood heat-treated to 56 °C core for 30 min; certificates available for customs clearance in AU, US, EU.

---

H3 3. Moisture & Corrosion Control

1. Barrier film: 7-layer co-extruded PE/PA/EVOH, water-vapour transmission ≤ 0.2 g/m²·24 h.
2. Desiccant quantity calculated per DIN 55474:
   n = 1.6 · A · e · (RHmax – RHtarget) / a
   where A = inner surface (m²), e = climate factor, a = desiccant capacity. Average loading 4 kg per 20 ft container.
3. Data loggers (Elpro LIBERO Ti1) record T & RH every 30 min; PDF report e-mailed on arrival.

---

H3 4. Container Stowage & Lashing

Gauge	Stowage Pattern	Lashing Points	Max Stack Height	COG from Deck
23Q110 coils	Eye-to-sky, 2 tiers	8 web lashings 2500 daN, twist-lock base	2.0 m	0.9 m
30QG120 sheets	Criss-cross, interlocked	4 corner castings, polyester strap	1.8 m	0.75 m

Container floor pre-lined with 5-ply Kraft + PE sheet; anti-slip mats 5 mm under each pallet.

---

H3 5. Logistics Corridor – Luoyang to Global

Factory GPS: 34.62 °N, 112.45 °E, 30 km to Lianyungang–Khorgos expressway.
Port coupling: Daily block-train to Qingdao (18 h), alternatively Lianyungong for Belt-&-Route routes.
Shipping lines: COSCO, MSC, CMA-CGM fixed allocations; peak-season space reserved 3 months ahead.
Transit time benchmarks:
– Qingdao → Hamburg 26 days
– Qingdao → Los Angeles 13 days
– Qingdao → Mumbai 14 days

Incoterms offered: FOB Qingdao, CIF main port, or DAP transformer plant. Customs HS-code 7225.11 pre-registered; CO, Form A, and mill test certificates (MTC EN 10204-3.1) shipped same day goods on vessel.

---

H3 6. Cost Advantage vs. Western Suppliers

By integrating annealing, coating and slit-to-width in one Luoyang campus, we eliminate one trans-loading step typical of EU mills. Freight + packaging cost equals only 4.2 % of coil value versus 7–9 % for European or Japanese sources. Customers save on average USD 38–52 per tonne landed, while meeting identical IEC 60404-8-7 magnetic specifications.

Need a project-specific packing diagram or desiccant calculation? Send us your coil OD/ID and destination port—our logistics engineers will return a verified stowage plan within 12 h.

---

Sourcing from Luoyang Xinzhaohe

Why Partner with Luoyang Xinzhaohe for Silicon Steel Grades

20+ Years of Transformer-Grade Refinement

Since 2003 we have supplied >1.2 million tonnes of electrical steel to tier-1 transformer OEMs, motor rewind shops and power-grid EPCs. Every coil is processed in our Luoyang plant—no trading middle-men—so magnetic data on the mill certificate is identical to the material that arrives on your dock. Our process metallurgists speak IEC 60404-2, ASTM A876 and JIS C 2552 as a first language; we translate those standards into measurable cost-of-ownership savings for you.

Direct Factory Price – Transparent Benchmark

The table below compares typical Q2-2024 FOB China prices for fully-processed, laser-scribed GOES and high-grade NGOES. Add your freight and duty; the delta versus European or Japanese mill quotes is 11–18 % landed cost advantage in most regions.

Grade (0.30 mm)	Core Loss @ 1.7 T / 50 Hz (W kg⁻¹)	Min. Flux Density B800 (T)	Lamin. Flatness (I-unit)	FOB Luoyang (USD/tonne)	Typical EU Mill (USD/tonne)
23QG085	0.85	1.89	≤ 3	1 180	1 350
27QG090	0.90	1.88	≤ 3	1 120	1 290
30QG105	1.05	1.87	≤ 3	1 050	1 220
35WW270 NGOES	2.70	1.68	≤ 5	890	1 040

Prices valid for 20 t minimum slit-width program; payment 30 % TT advance, 70 % BL copy. Volume rebates apply ≥ 200 t per quarter.

Customization Capabilities – Slit, Anneal, Coat, Cut in One Workflow

Our closed-loop line is purpose-built for electrical steel, not general cold-rolled strip. This keeps residual stress < 10 MPa and guarantees coating uniformity that meets DIN 46400 insulation class C5 or your in-house spec.

Work Package	Tolerance Band	Added Lead-Time	Value to You
Slitting 5–650 mm	± 0.03 mm	0 days	Eliminate edge burr, reduce building factor 1–2 %
Stress-relief anneal 780 °C, N₂-H₂	ΔP17/50 ≤ 0.02 W kg⁻¹	+ 2 days	Recover 3–5 % permeability lost in shearing
K-5 C6 insulation coating 0.8–1.2 µm	Breakdown ≥ 100 V per layer	inline	Withstand 180 °C varnish cure, inter-lamination resistance ≥ 30 Ω·cm²
Precision die-cut & step-lap	Angular deviation ≤ 0.05°	+ 3 days	Reduce no-load loss additional 4–6 % in 3-phase EI cores

We warehouse 3 000 t of prime CRGO and 5 000 t of high-grade NGOES in 0.23–0.50 mm, ready for same-day slitting. That means prototypes can ship in 7 calendar days; series orders in 3–4 weeks ex-works.

Premium Alternative to Western Mills – Without the Premium

Western producers add 8–12 % alloy surcharge every quarter and 6-month lead times. By controlling the full value chain—pickling, tandem cold rolling, decarburizing, MgO coating, high-temperature flattening anneal and laser magnetic domain refinement—we compress lead time and pass alloy savings straight to you. Our ISO 9001- and ISO 14001-certified system is audited by Siemens, Schneider and Hitachi Energy; PPAP level 3 documentation is standard.

Next Step – Request a Technical Datasheet or Quote

Send your core-loss target, stack dimension and annual volume to cathy@transformerstrip.com. We will return a detailed datasheet with guaranteed magnetic values, insulation class and FOB price within 24 h. Need a small trial slit? 500 kg minimum order available for new OEM programs.

---
