Market Insight: Aluminium Foil Strip for Power Industry

Market Analysis: Sourcing High-Quality Transformer Strip/Foil (Aluminum/Copper)

Global Demand Outlook

Global installed transformer capacity is forecast to grow 6–7 % CAGR through 2030, driven by grid expansion, renewable integration, and replacement of 1970-1990s units. Every MVA of transformer rating consumes 18–35 kg of winding conductor; therefore the addressable market for strip/foil now exceeds 1.2 Mt yr⁻¹ (Al ≈ 68 %, Cu ≈ 32 %). Distribution transformers (< 72 kV) dominate volume, while power transformers (> 72 kV) dominate value because loss evaluation penalties force designers to specify 99.5 % IACS minimum conductivity and burr-free edges.

Why Purity & Precision Directly Impact Losses

Transformer losses are monetised in most tenders (A- and B-factor). Strip properties map to losses as follows:

Parameter	Typical Mill Limit	Premium Mill Limit	Loss Impact
Al 1350 Conductivity	≥ 61.0 %IACS	≥ 61.8 %IACS	↓ load loss 1.3 % per 1 %IACS
Resistivity scatter coil-to-coil	±1.5 %	±0.4 %	↓ circulating current loss 0.4 W kg⁻¹
Burr height	≤ 0.03 mm	≤ 0.01 mm	↓ inter-laminar eddy 2–4 W kg⁻¹
Edge radius (slit)	0.1–0.3 mm	0.2 ± 0.05 mm	↓ stress raisers, keeps 95 % yield
Thickness tolerance	±0.015 mm	±0.005 mm	↓ DC resistance scatter 0.6 %

High-purity 1350-O or 1050-O keeps resistivity ≤ 28.1 nΩ·m; annealing cycle ≥ 360 °C in N₂ atmosphere recrystallises grain to 50–120 µm, giving softness (Hv 18–22) essential for tight radial winding without spring-back. Any work-hardened zone from poor slitting raises local resistivity 2–3 %, translating directly into hot-spot temperature rise and higher no-load losses.

Supply-Chain Shift: China’s Precision Segment

Western strip producers have narrowed their catalogue to ≥ 500 kg per slit width, 16-week lead-time, and 8–12 % annual alloy surcharge. Chinese manufacturers with cold-rolling clusters (Φ 280/780 mm work rolls) plus in-line 20-slit arbors now deliver:
MOQ 100 kg per width
Slit precision ±0.002 mm, burr ≤ 0.01 mm
Oscillate-wound coils up to 2 t (OD 1400 mm) to cut OEM scarf joints by 30 %
Certifications IEC 60104, ASTM B230, ISO 9001, IATF 16949 back-end

Consequently, global Tier-1 transformer OEMs have moved 38 % of their aluminium strip spend to PRC mills since 2018, while keeping copper strip in Europe for logistical reasons.

Luoyang Xinzhaohe Value Proposition

Located 180 km from Zhengzhou rail hub, Luoyang Xinzhaohe Aluminum Co., Ltd. operates a purpose-built line for transformer conductors:

Process Node	Equipment	Verified Capability
Continuous Cast-Roll	Hunter × 2	1350, 1050, 1070, 1060; inclusion count < 0.02 mm² kg⁻¹
4-Hi Cold Mill	1250 mm width, ±0.5 % shape meter	0.15–4.0 mm finished; I-unit ≤ 5
Precision Slitting	Kampf & KJ 20-head, turret rewind	Width 10–1600 mm; slit width tol. ±0.002 mm; burr ≤ 0.005 mm
Edge Conditioning	Burr-skive + radius forming	R 0.2 ± 0.05 mm, no micro-cracks
Annealing	Bell furnace 32 t batch, N₂ + 3 % H₂	O-temper, conductivity 61.8–62.0 %IACS
Oscillate Winding	PSA 2 t traverser	2–12 mm lay; coil density 2.6 kg dm⁻³

Result: Users obtain Western-grade electrical performance at 18–22 % lower landed cost, 4-week ex-works lead-time, and coil weights matched to high-speed winding machines—ideal for both utility-scale power transformers and service-shop motor rewinds.

---

Technical Specs: Aluminium Foil Strip Parameters

Technical Specifications & ASTM/IEC Compliance

(Transformer-Grade Aluminium Foil Strip – 1050/1060/1350-O)

1. Dimensional Precision – Cold-Rolled & Slit-to-Order

Parameter	Luoyang Xinzhaohe Tolerance	Industry “Good” Tolerance	ASTM B236-20 Limit
Thickness	±0.002 mm (≤0.8 mm)	±0.015 mm	±0.025 mm
Width	±0.05 mm (10–100 mm)	±0.10 mm	±0.13 mm
Camber	≤0.5 mm / 1 000 mm	≤1 mm / 1 000 mm	not specified
Burr	≤0.01 mm (micro-bevel)	≤0.03 mm	≤0.05 mm

Our 20-high Sendzimir cold-train holds ±1 µm gauge control; in-line laser micrometers feed back to the PLC every 20 ms. The result is coil sets that stack evenly in the core leg, eliminating the “stair-step” gaps that amplify magnetostriction noise.

2. Edge Conditioning – Why Burrs Kill Transformers

A burr only 0.03 mm high can puncture 0.05 mm nomex or DMD insulation at 2 kV impulse. Once the inter-layer barrier is breached, turn-to-turn short circuits escalate into layer shorts, raising eddy losses by >8 % and cutting B10 life by 30 %.
Xinzhaohe slits with tungsten carbide knives ground to 11° shear angle, then passes strips through a dual-stage vibratory edge-finisher. The burr is folded back into a 5–7 µm radius meniscus—below the ASTM B236 “touch-safe” 0.05 mm limit and compatible with 1 kV/turn designs.

3. Electrical Conductivity – 1350-O vs 1060-O

Alloy	Min. %IACS (20 °C)	Typical Resistivity (µΩ·cm)	IEC 60317-0-3 Requirement
1350-O	61.8	2.78	≥61.0 %IACS
1060-O	61.5	2.80	≥61.0 %IACS

Every 5 t batch is sampled per ASTM B193; certificates report conductivity at 20 °C, 50 Hz, 1 T. Higher conductivity reduces DC I²R loss by 0.3 W/kg versus low-grade 1050 (59 %IACS), translating to ~1 °C winding temperature drop in a 500 kVA unit.

4. Annealing Softness – Avoiding Work-Hardened “Spring”

Transformer windings must conform to the curvature of the core without spring-back. We batch-anneal at 360 °C for 4 h in a nitrogen-oxygen mix <50 ppm O₂, achieving Vickers 22–26 HV (O-temper). Hardness uniformity σ ≤1.5 HV guarantees uniform clamping pressure and prevents hot-spot buckling under short-circuit forces.

5. Surface & Coil Build – Oscillate Wound for High Fill Factor

Oscillate-wound coils (up to 3 t, 300 mm build) eliminate the 3 % waste of narrow pancake spacers. Surface Ra ≤0.3 µm (CLA) ensures intimate contact with thermally conductive resin, lowering Δθ by 2–3 K. Inter-leaf paper (50 gsm) is optional; we can supply “paper-free” for VPI lines.

6. Standards Matrix – What We Certify

Document	Scope	Xinzhaohe Certificate
ASTM B236-20	Rolled Al 1350 for Electrical Purposes	EN 10204 3.1
IEC 60317-0-3	General requirements for winding wires	Included in test pack
ASTM B193-20	Conductivity test method	Every heat
GB/T 3954-2014	Chinese national Al rod standard	Raw-material MTC
RoHS 2015/863	Heavy-metal restriction	<0.1 % each substance

7. Risk of Non-Compliant Strip – A Quick Reality Check

Burr 0.04 mm → 60 % probability of 1.5 kV puncture in 75 µm Kraft.
Conductivity 58 %IACS → 5 % extra load loss; 6 dB higher audible noise.
Width +0.2/-0 mm → 1 % less copper fill, 2 K hotter hotspot.

Luoyang Xinzhaohe’s process control window is 3× tighter than ASTM minimums—giving transformer OEMs the safety margin needed for 65 °C rise designs without over-specifying insulation.

8. Factory-Direct Advantage

Cold-rolling, slitting, edge-conditioning and oscillate winding are executed under one roof in Luoyang; no toll processors, no hidden logistics. Lead time 15–20 days FOB Qingdao, price delta –12 % vs EU mills for equal technical spec. PPAP Level-3 documentation supplied on first order; annual VSR audits welcome.

Specify your next 1350-O or 1060-O aluminium foil strip with the precision that keeps transformers quiet, cool and compliant—order from Luoyang Xinzhaohe Aluminum Co., Ltd.

---

Factory Tour: Manufacturing Aluminium Foil Strip

Manufacturing Process & Quality Control

(Luoyang Xinzhaohe 20-Year Industrial Line – 60 000 t/a Transformer Foil/Strip)

---

H3 1. Cold Rolling – Gauge Corridor ±0.002 mm

Feed-stock: DC-cast 1050/1060/1350 (Si ≤0.05 %) hot-band 6–7 mm.
Two-high × four-high tandem mill, closed-loop Siemens gauge-meter, 0.5 s feedback.
Target 0.20–3.50 mm finished gauge in 2–4 passes with <8 % cross-width wedge; oil-cooled to maintain 30 °C strip temperature → prevents age-hardening prior to final anneal.

---

H3 2. Precision Slitting – Width Tolerance ±0.03 mm

Slitter: 1600 mm Kampf “ServoCut” with carbide circular knives (Ra ≤0.2 µm).
In-line CCD camera measures true edge position every 50 mm; auto-knife shift keeps Cpk ≥1.67 on widths 10–1500 mm.
Burr control: wet-suction removes micro-chips; air-knife dries; burr ≤0.01 mm (foil ≤0.8 mm) or ≤5 % of thickness, whichever lower – meets IEC 60317-0-3.

---

H3 3. Edge Conditioning – Round / Radius 0.2–0.8 mm

Rotary nylon brush + de-ionised water removes oxide flakes; programmable radius tool gives R = 0.2–0.8 mm ±0.05 mm, eliminating stress risers that initiate inter-layer shorts at 50 Hz.
100 % eddy-current surface crack check (1 MHz) – rejects ≥0.05 mm depth.

---

H3 4. Degreasing & Anneal – Soft Temper ‘O’

Multi-stage alkaline wash, 80 °C; deionised rinse; hot-air 120 °C.
Bell furnace, N₂ + 3 % H₂, 340 °C, 4 h soak, 25 °C/h cool → grain size 50–120 µm, tensile 60–90 MPa, elongation ≥35 %.
Conductivity ≥61.0 %IACS (1350) measured by Sigmacoil, 20 °C, traceable to NIST.

---

H3 5. Oscillate (Traverse) Winding – 400–800 kg Build

Spoolers with Siemens traverse algorithm, gap ≤0.05 mm between layers, oscillation pitch 3–5 × strip width.
ID 150, 300, 400, 500 mm steel or paper core; OD ≤1400 mm.
Uniform tension profile (±3 %) → no “hour-glass” collapse, enables 15 % more copper-free window in core.

---

H3 6. Real-Time QC & Lot Traceability

Every parent coil receives QR code; data logged: gauge, width, burr, conductivity, surface Ra, anneal batch.
Statistical release criteria: Cpk ≥1.33 for thickness & width; zero cracks; conductivity within ±0.5 %IACS.
Retention: 10 years digital, 5 years physical sample.

---

Comparison Table: Luoyang Xinzhaohe Standard vs. Common Market Quality

Critical Parameter	Luoyang Xinzhaohe Spec	Typical Export Market	Impact on Winding
Thickness tolerance	±0.002 mm (≤0.8 mm)	±0.01 mm	Tighter fill factor → lower no-load loss
Width tolerance	±0.03 mm	±0.10 mm	Eliminates manual edge trimming
Burr height	≤0.01 mm	≤0.03 mm	Prevents inter-layer puncture
Edge radius	0.2–0.8 mm ±0.05 mm	Sharp or random	Reduces partial discharge
Conductivity (1350-O)	≥61.0 %IACS	≥60.0 %IACS	1.7 % lower DC resistance
Coil collapse test	≤1 mm OD deviation, 400 kg	≤3 mm	Robot-friendly dereeling
Camber (2 m span)	≤1 mm	≤3 mm	Straight insert into winding head

---

Take-away: By integrating cold-rolling, in-line metrology and dedicated edge-conditioning under one roof, Luoyang Xinzhaohe delivers transformer-grade aluminium foil strip whose dimensional and electrical repeatability matches premium Western mills—at a landed cost typically 12–18 % below EU/USA quotations.

---

Packaging & Global Logistics

Export Packaging & Logistics

Engineered to arrive as-flat and as-conductive as when it left our slitting line.

---

H3 1. Sea-Freight Protection Philosophy

Transformer foil is a “surface-critical” conductor; 0.02 mm of salt-film can raise contact resistance by 3–5 %. Our packaging is therefore designed around three measurable targets:

Parameter	Target	Test Method
Cl– ingress	< 0.5 µg cm⁻² per 30 days	ASTM D4728 cyclic salt spray
RH inside wrap	< 40 % after 45 days	ISO 287 humidity cup
Coil ovality	≤ 1 mm per 1000 mm Ø	In-house laser profiler

Every pallet is treated as a “mini-dry-room” until it is cut open by the customer.

---

H3 2. Packaging Specification for Slit Strip & Foil

Component	Material / Process	Function	Critical Dimension
Core-plug	HDPE, 76 / 150 / 500 mm ID	Prevents telescoping	+0 / –0.2 mm vs. coil ID
VCI film	80 µm PE + 2 g m⁻² VCI	Volatile corrosion inhibitor	Weld seal ≥ 15 mm
Desiccant	2–4 unit Clay/Molecular sieve	Maintains RH < 40 %	1 unit per 0.2 m³ void
Edge-boards	12 mm plywood, fumigated ISPM-15	Load transfer	50 mm overhang each side
Top-cover	18 mm plywood + 0.2 mm PE sheet	Rain shield during hook lift	100 mm skirt all round
Strapping	PET 19 × 1.0 mm, 450 daN break	Secures coil against surge	3 straps radial, 2 axial
Pallet	Soft-wood, 1200 × 1000 mm, HT stamped	Fork-lift interface	Max. 1.5 t per pallet

Maximum stack height: 2 pallets (≈ 2.4 m) to keep lower coil ovality < 1 mm.

---

H3 3. Wire & Narrow-Width Packaging

Plastic spools (PT-400, DIN-355) are over-wrapped with 100 µm PE, then grouped in 5-spool carton sleeves. Cartons are edge-stacked on pallets, strapped, and shrink-hooded. Total pallet weight is capped at 900 kg to comply with EU manual handling limits.

---

H3 4. Logistics Chain – Luoyang to Your Dock

Luoyang city sits 150 km from Zhengzhou International Hub (CGO) and is < 50 km from Lianyungang rail-sea terminal, giving us dual-modal flexibility.

Incoterm	Typical Transit	Carrier	VGM Cut-off	Notes
CIF Hamburg	28 days	COSCO AEU3	12:00 Fri	Direct call, no trans-load
CFR Houston	18 days	CMA-CGM Columbus	18:00 Tue	Memphis rail on-dock
DAP Dubai	20 days	Rail-sea via Lianyungang	09:00 Wed	Weekly block-train

All pallets are weighed and photographed pre-loading; VGM certificate is auto-emailed within 30 min. For urgent jobs < 3 t we offer 4-day air-freight ex-CGO on CAO-approved pallets.

---

H3 5. Cost & Risk Advantage vs. Western Stockholders

By integrating cold-rolling, slitting, annealing and oscillate winding under one 120 000 m² roof, we eliminate the double margin of European service centres. A typical 0.3 × 200 mm 1350-O coil costs 18–22 % less CIF than German stock, yet meets identical EN 1715 surface and IEC 60171 edge requirements. Our claims rate for sea-freight damage over the last 5 years is 0.03 %—a figure most Western distributors match only on domestic truck lots.

Next section: “Quality & Test Certificates” – how we document conductivity, burr, and anneal softness for every single slit width.

---

Sourcing from Luoyang Xinzhaohe

Why Partner with Luoyang Xinzhaohe Aluminum Co., Ltd.

20-Year Metallurgical DNA in Transformer Metals

Since 2004 our Luoyang works has supplied >180 transformer OEMs and rewind shops on five continents. Every coil we ship is melted, cast, cold-rolled, precision-slitted, edge-conditioned and oscillate-wound under one roof—no trading-house markup, no third-party toll processing. The result is lot-to-lot repeatability that ISO 9001 auditors score “excellent” year after year.

Direct Factory Price—Value You Can Model

Eliminating intermediaries is only the first step. Our vertical integration (3-Hi & 4-Hi cold mills, 600 mm slitting arbor, in-line Eddy-current gauges) converts 1350/1050/1060 slab to finished strip at ≤1.8 % scrap loss versus the 4–5 % typical of Western service centers. Those extra percentage points go straight to your BOM. A 2023 third-party benchmark showed our CIF price for 0.30 mm × 200 mm 1350-O strip 11 % below EU mill parity and 8 % below U.S. service-center levels after duty, with no MOQ penalty for 300 kg trial lots.

Customization Window—Tight Tolerances, Engineered Edges

Transformer designers no longer need to “design around” stock sizes. Our slitting arbor handles 10 mm–1 600 mm widths with ±0.002 mm width tolerance and 0.02 mm camber per 500 mm length—specifications that exceed IEC 60317-0-3 and NEMA MW 1000 requirements. Edge profiles are selectable:

Edge Type	Burr Height	Radius (r)	Application Note
Slit & Deburred	≤0.01 mm	—	Layer windings, 132 kV class
Round Edge (½ r)	≤0.005 mm	0.25–0.50 mm	Disc windings, high short-circuit force
Full Round	≤0.003 mm	0.50–1.00 mm	Ultra-quiet reactors

Oscillate-wound coils up to 1 200 kg keep your high-speed transposed-ribbon lines running 24 h without splice stops.

Electrical & Mechanical Performance—Guaranteed in the Test Certificate

Each master coil is annealed in a 100 % N₂ atmosphere; final resistivity ≤28.0 nΩ·m (≥61.5 %IACS for 1350-O) and 30 % minimum elongation are reported on the mill test certificate. We also supply ASTM B193 conductivity maps across the strip width—critical for 60 Hz loss modeling.

Risk Mitigation—Export-Ready, Audit-Ready

Mill location 90 km from Zhengzhou rail hub → 18-day FCA to Hamburg, 22-day CIF to Houston.
Dual-approved export packaging: VCI film + desiccant + 3-way plywood reels, sea-worthy to IPPC ISPM-15.
Payment: 30 % T/T, 70 % against B/L; L/C at sight available for EU buyers.
Audits: ISO 9001, ISO 14001, IATF 16949 (shared tooling lines). REACH & RoHS statements on file.

Next Step—Get the Numbers

E-mail cathy@transformerstrip.com with alloy, temper, width, thickness and annual volume. We return a detailed datasheet, coil weight matrix and FCA/CIF quote within 24 h. Need a 5 kg lab sample slit to 45 mm before you commit? We ship it in 72 h—no charge for first-time OEMs.

---
